BBK DK2810HD - Page 118

0880499 IC L7805CV GOLD SEALED TO-220
U508 ⑧
0880553 IC L431ACZ TO-92
U503,U506 ⑨
0882089 IC TL431 TO-92
U503,U506 ⑨
0882462 IC AZ431AZ-A TO-92
U503,U506 ⑨
0882041 IC MI431C TO-92
U503,U506 ⑨
0881480 IC NCP1200P60 DIP U501
0881500 IC 10880BTU TO-35L U504
1030007 PRESS SENSITIVITY RESISTOR 7D 471±10% 5mm RV501
1050002 HEAT SENSITIVITY RESISTOR NTC SC104MS±20% RT501
1080011 PHOTOELECTRIC COUPLER HS817 U502,U505,U507
1570241 PCB
@5 1910SI4-3 CEM1 D1.6 SX @UL C043
1940003 SOCKET 4P 2.5mm XS101
1940006 SOCKET 6P 2.5mm XS102
1940009 SOCKET 8P 2.5mm XS104
1940074 SOCKET 2P 7.92mm XS100
2300072 FUSE @T3.15AL 250V 3.6×10 VDE F501
3580195 HEAT RADIATION BOARD
11×15×25 SINGLE HOLE,NOT OXIDATION
D516,D517,V501
3580091 HEAT RADIATION BOARD 11×15×31 9905 U508
3580260 HEAT RADIATION BOARD
30×19.8×35 2100 NON-OXIDATION
U504
5230462 MICA PAD 24×20×0.1
BETWEEN U504 AND HEAT RADIATION
BOARD
3870115
GROUND CHIP OF POWER BOARD
903 GND501,GND502
4000453 SELF-TAPPING SCREW BT 3×8H WHITE NICKEL V501,U508,D516,D517
4000564 SELF-TAPPING SCREW PWT 3×12×7H WHITE NICKEL U504
MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0310222 SMD CAPACITOR 25V 104±20% 7R 0603
C3 ,C5
0310191 SMD CAPACITOR 50V 30P±5% NPO 0603
C1, C2
0090029 SMD RESISTOR 1/16W 47K±5% 0603
R2
0090233 SMD RESISTOR 1/16W 4.7MO±5% 0603
R3, R4
0090002 SMD RESISTOR 1/16W 2.2O ±5% 0603
R5
0700007 SMD DIODE 14148
VD2
0970008 CERAMIC RESONATOR 2.0MHz
G1
0090008 SMD RESISTOR 1/16W 220O±5% 0603
R6
DVD RECEIVER DK2810HD(RU) BLACK
REMOTE CONTROL 5471746
