0630003
EMISSION PIPE TSAL6200
LED1
0160217 DIGITAL POTENTIOMETER EC30P16
RP1
1340190
LIGHT TOUCH SWITCH(FIVE DIRECTION)
SKQUC010
RP2
0780085 SMD TRIODE 8050D
V1
1564473 PCB 81910SI-2
2100003 CONNETION CORDS F0.6 SHAPED 7.5mm W1
3031855
SURFACE CASING OF REMOTE CONTROL
RC-073 BLACK
3041406
BOTTOM CASING OF REMOTE CONTROL
RC-073 BLACK
3051348
BATTERY CASE DOOR OF REMOTE CONTROL
RC-073 BLACK
3051349 GLASS O REMOTE CONTROL RC-073 MING PURPLE
3850124 ANODE SPRING RC026
3850125 CATHODE SPRING RC026
3850126 ANODE/CATHODE SPRING RC026
3072572 5-DIRECTION BUTTON RC-073 GREEN
3072570 VOLUME KNOB RC-073 BLACK
4000179 SELF-TAPPING SCREW PB 2×8 BLACK
0890292 PROGRAM CPU CPU073RU-0
4631058
CONDUCT GLUE OF REMOTE CONTROL(UPPER)
RC-073
4631059
CONDUCT GLUE OF REMOTE CONTROL(LOWER)
RC-073
5071274
PLASTIC BAG FOR ENVIRONMENTAL PROTEETION
（
85×290×0.05 PE
MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0570006 DIODE 1N4148 VD1~VD4
0780025 TRIODE 25401 V101
0000133 CARBON FILM RESISTOR 1/64.7K±5% SHAPED 7.5 R101,R115~R119
0000137 CARBON FILM RESISTOR 1/610K±5% SHAPED 7.5 R102~R105,R107,R108,R127,R126
0160227 DIGITAL POTENTIOMETER ED200120-A20-100-G77 RP101
0000142 CARBON FILM RESISTOR 1/633K±5% SHAPED 7.5 R114
0000556 CARBON FILM RESISTOR 1/647O±5% SHAPED 7.5 R125
0000122 CARBON FILM RESISTOR 1/6100O±5% SHAPED 7.5 R110,R113
0000488 CARBON FILM RESISTOR 1/6220O±5% SHAPED 7.5 R120,R122
0000452 CARBON FILM RESISTOR 1/6150O±5% SHAPED 7.5 R124
0260076 CD CD11C 50V22U±20%6×7 2.5 TC112
DVD RECEIVER DK2810HD(RU) BLACK
SURFACE CONTROL BOARD: 4DK2870HD-0 4940419
