0260780 CD CD11C 10V47U±20%4×7 C2.5 TC104~TC106,TC100
0200123 PORCELAIN CAPACITOR 50V 102±10% 5mm C110,C111
0200138 PORCELAIN CAPACITOR 50V 104±20% 5mm C101~C103
0200108 PORCELAIN CAPACITOR 50V 221±5% 5mm C107~C109
0620218 RADIATION DIODE 3B 2PW WHITE ISSUE BLUE VD106,VD107,VD105
1340064
LIGHT TOUCH RESTORE SWITCH
KFC-06-2WB L3.8 S104~S109,S110
2360021 IR SENSOR 138BV3 N102
2100010 CONNETION CORDS F0.6 SHAPED 5mm J119,J120,J118
2100003 CONNETION CORDS F0.6 SHAPED 7.5mm
J101,J107,J110,J113,J115,J116,J121,R109,R11
1,R112
2100004 CONNETION CORDS F0.6 SHAPED 10mm
J102,J103,J105,J106,J108,J109,J111,J112,J114,
J117
0200136 PORCELAIN CAPACITOR 50V 473±20% 5mm C114,C115
3074849 LED BRACKET H=5MM LED-5 VD107
0882414 IC TP6317 LQFP44 N101
1200653 IAY SCREEN HL-D593 DS101
5236518 SOFT ONGE ACER
14×10×6.5 DOUBLE-FACED,HARD(50 DEGREE)
2PCS FOR DISPLAY SCREEN/ SURFACE
CONTROL BOARD
5237027 SOFT SPONGE SPACER 7×7×9.5 DOUBLE-FACED,HARD
1PC FOR IR SENSOR/SURFACE CONTROL
BOARD
2122733 FLAT CABLE
6P95 2.5/2.0 2PIN, WITH L NEEDLE, TOGETHER DIRECTION SEPARATE CORD
XP102
2122734 FLAT CABLE
6P140 2.0 2PIN, WITH L NEEDLE, TOGETHER DIRECTION SEPARATE CORD
XP106
0010335 METAL OXIDE FILM RESISTOR 1/4W 0.47O±5% SHAPED 10 R128,R129
1564911 PCB 4 2870HD-0 HB D1.6 SX
MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0883034
IC 37544G2AGP LQFP
N1
5156608
SIGN STICKER CPURC073RU-0
STICK ONTO IC0883034
MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0881998 IC 49BV162A 70TI TSOP
N83 ⑩
0881754 IC 29LV160BE-70NC TSOP
N83 ⑩
REMOTE CONTROL SOFEWARE PROGRAM CPURC073RU-0 0890292
PROGRAM FLASH ROM2870SIRU-0A(16M) 0912022
DVD RECEIVER DK2810HD(RU) BLACK
DVD RECEIVER DK2810HD(RU) BLACK
- 114 -
