- 54 -
Pin Main Alt. Type Description
78 IOOE#
Inout
4~16MA, SR
SMT
Flash output enable, active low / IO
66 IOWR#
Inout
4~16MA, SR
SMT, PU
Flash write enable, active low / IO
76 IOCS#
Inout
4~16MA, SR
SMT
Flash chip select, active low / IO
94 UWR#
Inout
4~16MA, SR
SMT, PU
Microcontroller write strobe, active low
95 URD#
Inout
4~16MA, SR
SMT, PU
Microcontroller read strobe, active low
97 UP1_2
Inout
4MA, SR
SMT, PU
1) Microcontroller port 1-2
2) HSYNC or VSYNC
98 UP1_3
Inout
4MA, SR
SMT, PU
Microcontroller port 1-3
99 UP1_4
Inout
4MA, SR
SMT, PU
Microcontroller port 1-4
100 UP1_5
Inout
4MA, SR
SMT, PU
Microcontroller port 1-5
101 UP1_6 SCL
Inout
4MA, SR
SMT, PU
1) Microcontroller port 1-6
2) I2C clock pin
102 UP1_7 SDA
Inout
4MA, SR
SMT, PU
1) Microcontroller port 1-7
2) I2C data pin
