Pin Main Alt. Type Description
103 UP3_0 RXD
Inout
4MA, SR
SMT, PU
1) Microcontroller port 3-0
2) 8032 RS232 RXD
104 UP3_1 TXD
Inout
4MA, SR
SMT, PU
1) Microcontroller port 3-1
2) 8032 RS232 TXD
105 UP3_4 RXD SCL
Inout
4MA, SR
SMT, PU
1) Microcontroller port 3-4
2) Hardwired RD232 RXD
1) 2nd I2C clock pin
106 UP3_5 TXD SDA
Inout
4MA, SR
SMT, PU
1) Microcontroller port 3-5
2) Hardwired RD232 TXD
3) 2nd I2C data pin
GPIO interface ( 9 )
157 GPIO4
Inout
2~8MA
PD
1) GPIO4
2) MS_D0 (1st set of MS_SD)
3) SPDF_LRCK
4) HSYNC or VSYNC
158 GPIO5
Inout
2~8MA
PD
1) GPIO5
2) MS_BS (1st set of MS_SD)
3) SPDF_BCK
4) HSYNC or VSYNC
159 GPIO6 DDC_DA
Inout
2~8MA
PD
1) GPIO6
2) DDC Data Pin
3) MS_CLK (1st set of MS_SD)
4) SPDF_ACK
161 GPIO7 DDC_CLK
Inout
2~8MA
PD
1) GPIO7
2) DDC CLK Pin
3) MS_D1 (1st set of MS_SD)
4) SPLIN_SDATA
162 GPIO8 HTPLG
Inout
2~8MA
PD
1) Hot Plug detection
2) GPIO8
3) MS_D2_1 (1st set of MS_SD)
4) AUDIO_MUTE
5) MCDATA
6) ASDATA5
