Pin Main Alt. Type Description
210 GPIO9 YUVCLK
Inout
2~8MA
PD
1) GPIO9
2) C3 (1st set of CCIR656)
3) YUVCLK (2nd set of CCIR656)
4) MS_D3 (1st set of MS_SD)
5) MCDATA
6) ASDATA4
7) AUDIO_MUTE
211 GPIO10
Inout
2~8MA
PD
1) GPIO10
2) C2 (1st set of CCIR656)
3) SD_D3 (1st set of MS_SD)
4) ALRCK
5) SACD_FRAME_CLK
213 GPIO11
Inout
2~8MA
PD
1) GPIO11
2) C1 (1st set of CCIR656)
3) SD_D2 (1st set of MS_SD)
4) ABCK
5) SACD_ANSILLARY
214 GPIO12
Inout
2~8MA
PD
1) GPIO12
2) C0 (1st set of CCIR656)
3) SD_D1 (1st set of MS_SD)
4) ACLK
5) ASDATA5
Audio interface ( 19 )
215 SPDIF GPIO23
Inout
2~8MA, SR :
ON/OFF
Non-pull
1) SPDIF output
2) GPIO23
216 APLLVDD3 Power 3.3V Power pin for audio clock circuitry
217 APLLCAP Analog Inout APLL External Capacitance connection
218 APLLVSS Ground Ground pin for audio clock circuitry
219 ADACVSS2 Ground Ground pin for AUDIO DAC circuitry
220 ADACVSS1 Ground Ground pin for AUDIO DAC circuitry
