Pin Main Alt. Type Description
206 TS_SYNC GPIO
Inout
2~8MA
PD
1) TS SYNC
2) C6 (1st set of CCIR656)
3) Digital Video output Y bit 2 (2nd set of CCIR656)
4) MCDATA
5) GPIO
205 TS_CLK GPIO
Inout
2~8MA
PD
1) TS Clock
2) C7 (1st set of CCIR656)
3) Digital Video output Y bit 3 (2nd set of CCIR656)
4) ALRCK
5) GPIO
204 TS_VALID SD_D3
Inout
2~8MA
PD
1) TS Valid
2) YUVCLK (1st set of CCIR656)
3) SD DATA3(IO) (2nd set of MS_SD)
4) Digital Video output Y bit 4 (2nd set of CCIR656)
5) ABCK
6) GPIO
203 TS_DATA7 SD_D2
Inout
2~8MA
PD
1) TS DATA7
2) Y0 (1st set of CCIR656)
3) SD DATA2(IO) (2nd set of MS_SD)
4) Digital Video output Y bit 5 (2nd set of CCIR656)
5) ACLK
6) GPIO
202 TS_DATA6 SD_D1
Inout
2~8MA
PD
1) TS_DATA6
2) Y1 (1st set of CCIR656)
3) SD DATA1(IO) (2nd set of MS_SD)
4) Digital Video output Y bit 6 (2nd set of CCIR656)
5) SPLIN_SDATA
6) GPIO
201 TS_DATA5 MS_D3
Inout
2~8MA
PD
1) TS DATA5
2) Y2 (1st set of CCIR656)
3) MS DATA3 (IO) (2nd set of MS_SD)
4) Digital Video output Y bit 7 (2nd set of CCIR656)
5) SPDF_LRCK
6) GPIO
