BBK DK2810HD - Page 64

- 60 -
Pin Main Alt. Type Description
200 TS_DATA4 MS_D2
Inout
2~8MA
PD
1) TS DATA4
2) Y3 (1st set of CCIR656)
3) MS DATA2(IO) (2nd set of MS_SD)
4) Digital Video output C bit 0 (2nd set of CCIR656)
5) SPDF_BCK
6) HSYNC or VSYNC
7) GPIO
199 TS_DATA3 MS_D1
Inout
2~8MA
PD
1) TS DATA3
2) Y4 (1st set of CCIR656)
3) MS DATA1 (IO) (2nd set of MS_SD)
4) Digital Video output C bit 1 (2nd set of CCIR656)
5) SPDF_ACK
6) HSYNC or VSYNC
7) GPIO
198 TS_DATA2 MS_CLK
Inout
2~8MA
PD
1) TS DATA2
2) Y5 (1st set of CCIR656)
3) MS CLK (2nd set of MS_SD)
4) Digital Video output C bit 2 (2nd set of CCIR656)
5) GPIO
197 TS_DATA1 MS_BS
Inout
2~8MA
PD
1) TS DATA1
2) Y6 (1st set of CCIR656)
3) MS BS (2nd set of MS_SD)
4) Digital Video output C bit 3 (2nd set of CCIR656)
5) GPIO
196 TS_DATA0 MS_D0
Inout
2~8MA
PD
1) TS DATA0
2) Y7 (1st set of CCIR656)
3) MS DATA0 (IO) (2nd set of MS_SD)
4) Digital Video output C bit 4 (2nd set of CCIR656)
5) GPIO
130 GPIO20 C_5
Inout
2~8MA
PD
1) SD_CMD (Both set of MS_SD)
2) Digital Video output C bit 5 (2nd set of CCIR656)
3) GPIO20
112 GPIO21 C_6
Inout
2~8MA
PD
I. SD CLK (Both set of MS_SD)
II. Digital Video output C bit 6 (2nd set of CCIR656)
III. GPIO21
