- 61 -
Pin Main Alt. Type Description
110 GPIO22 C_7
Inout
2~8MA
PD
I. SD D0 (Both set of MS_SD)
II. Digital Video output C bit 7 (2nd set of CCIR656)
III. GPIO22 IV. INT0#
USB2.0 ( 9 )
44 USB_DP Analog Inout USB port DPLUS analog pin
45 USB_DM Analog Inout USB port DMINUS analog pin
46 VDD33_USB USB Power USB Power pin 3.3V
47 VSS33_USB USB Ground USB ground pin
48 PAD_VRT Analog Inout USB generating reference current
49 VDD18_USB USB Power USB Power pin 1.8V
50 VSS18_USB USB Ground USB ground pin
51 USB_XTALO GPIO
Analog Output
INOUT
30M crystal out for USB 2.0
52 USB_XTALI GPIO
Analog Input
INOUT
30M crystal in for USB 2.0
HDMI TX ( 19 )
181 AGND18_TX0 Analog Power 1.8V GND FOR HDMI TX
180 TX2P Analog Output Postive TX CH2
179 TX2N Analog Output Negative TX CH2
178 AVDD18_TX0 Analog Power 1.8V VDD FOR HDMI TX
177 TX1P Analog Output Postive TX CH1
176 TX1N Analog Output Negative TX CH1
175 AGND18_TX1 Analog Power 1.8V GND FOR HDMI TX
174 TX0P Analog Output Postive TX CH0
173 TX0N Analog Output Negative TX CH0
172 AVDD18_TX1 Analog Power 1.8V VDD FOR HDMI TX
171 TXCP Analog Output Postive TX CLK
170 TXCN Analog Output Negative TX CLK
169 AGND18_TX2 Analog Power 1.8V GND FOR HDMI TX
168 AGND33_TX Analog Power 3.3V GND FOR HDMI TX
167 EXT_CAP Analog Input EXTERNAL CAPACITOR FOR HDMI TX
166 AVDD33_TX Analog Power 3.3V VDD FOR HDMI TX
165 AVDD33_VPLL Analog Power 3.3V VDD FOR HDMI TX
164 EXT_RES Analog Input EXTERNAL RESISTER FOR HDMI TX
