Pin Main Alt. Type Description
149 RA11
output
2~16MA, SR
SMT, PU, PD
DRAM address bit 11
147 CKE
output
2~16MA, SR
SMT, PU, PD
DRAM clock enable
146 RCLK
output
2~16MA, SR
SMT, PU, PD
Dram clock
144 RA3
output
2~16MA, SR
SMT, PU, PD
DRAM address 3
143 RA2
output
2~16MA, SR
SMT, PU, PD
DRAM address 2
141 RA1
output
2~16MA, SR
SMT, PU, PD
DRAM address 1
140 RA0
output
2~16MA, SR
SMT, PU, PD
DRAM address 0
139 RA10
output
2~16MA, SR
SMT, PU, PD
DRAM address 10
138 BA1
output
2~16MA, SR
SMT, PU, PD
DRAM bank address 1
137 BA0
output
2~16MA, SR
SMT, PU, PD
DRAM bank address 0
136 RCS#
output
2~16MA, SR
SMT, PU, PD
DRAM chip select, active low
