BBK DK2810HD - Page 68

- 64 -
Pin Main Alt. Type Description
135 RAS#
output
2~16MA, SR
SMT, PU, PD
DRAM row address strobe, active low
134 CAS#
output
2~16MA, SR
SMT, PU, PD
DRAM column address strobe, active low
133 RWE#
output
2~16MA, SR
SMT, PU, PD
DRAM Write enable, active low
132 DQM1
output
2~16MA, SR
SMT, PU, PD
Data mask 1
129 RD8
Inout
2~16MA, SR
PU, PD
DRAM data 8
128 RD9
Inout
2~16MA, SR
PU, PD
DRAM data 9
127 RD10
Inout
2~16MA, SR
PU, PD
DRAM data 10
126 RD11
Inout
2~16MA, SR
PU, PD
DRAM data 11
125 RD12
Inout
2~16MA, SR
PU, PD
DRAM data 12
124 RD13
Inout
2~16MA, SR
PU, PD
DRAM data 13
123 RD14
Inout
2~16MA, SR
PU, PD
DRAM data 14
