BBK DK2810HD - Page 69

- 65 -
Pin Main Alt. Type Description
122 RD15
Inout
2~16MA, SR
PU, PD
DRAM data 15
121 RD0
Inout
2~16MA, SR
PU, PD
DRAM data 0
120 RD1
Inout
2~16MA, SR
PU, PD
DRAM data 1
119 RD2
Inout
2~16MA, SR
PU, PD
DRAM data 2
117 RD3
Inout
2~16MA, SR
PU, PD
DRAM data 3
116 RD4
Inout
2~16MA, SR
PU, PD
DRAM data 4
115 RD5
Inout
2~16MA, SR
PU, PD
DRAM data 5
114 RD6
Inout
2~16MA, SR
PU, PD
DRAM data 6
113 RD7
Inout
2~16MA, SR
PU, PD
DRAM data 7
111 DQM0
output
2~16MA, SR
SMT, PU, PD
Data mask 0
3.5.2 function introduction to AT24C04
1. Description
The AT24C04 provides 4096 bits of serial electrically erasable and programmable read-only memory
(EEPROM) organized as 512 words of 8 bits each. The device is optimized for use in many industrial and
