- 74 -
14 VDDA
I
analog supply voltage (5 V)
15 VSSA
I
analog ground (0 V)
16 MPX
I
multiplex input signal
17 Vref
O
reference voltage output
18 SCOUT
O
band-pass filter output
19 CIN
I
comparator input
20 LVIN
I
level input
3.5.9 function introduction to 5340
1. DESCRIPTION
The CS5340 is complete analog-to-digital converter for digital audio systems. It performs sampling,
analog-to-digital conversion and anti-alias littering, generating 24-bit values for both left and right inputs in
serial form at sample rates up to 200 kHz per channel.
The CS5340 uses a 5th-order,multi-bit delta-sigma modulator followed by digital filtering and decimation,
which removes the need for an external anti-alias filter.
The CS5340 is ideal for audio systems requiring wide dynamic range, negligible distortion and low noise,
such as set-top boxes, DVD-karaoke players, DVD recorders, A/V receivers, and automotive applications.
2. FEATURES
◆ Advanced multi-bit Delta-Sigma architecture
◆ 24-bit conversion.
◆ Supports all audio sample rates including 192kHz.
◆ 101dB Dynamic Range at 5V.
◆ -94 dB THD+N.
◆ High pass filter to remove DC offsets.
◆ Analog/digital core supplies from 3.3V to 5V..
◆ Linear phase digital anti-alias filtering.
◆ Auto-mode selection.
3. PIN DESCRIPTION
PIN No. Symbol I/O Description
1 M0 I Mode selection 0
2 MCLK I Master clock
3 VL I Logic power
