- 75 -
4 SDOUT O Serial audio data output
5 GND I GND
6 VD I Digital power
7 SCLK I Serial clock
8 LRCK I Left right clock
9 /RST I Reset
10 AINL I Analog input L
11 VQ O Quiescent voltage
12 AINR I Analog input R
13 VA I Analog power
14 REF_GND I GND
15 FILT+ I Positive voltage reference
16 M1 I Mode selection 1
3.5.10 function introduction to TLV272
1. DESCRIPTION
The TLV27x takes the minimum operating supply voltage down to 2.7 V over the extended industrial
temperature range while adding the rail-to-rail output swing feature. This makes it an ideal alternative to the
TLC27x family for applications where rail-to-rail output swings are essential. The TLV27x also provides 3-MHz
bandwidth from only 550µA.
Like the TLC27x, the TLV27x is fully specified for 5-V and ±5-V supplies. The maximum recommended
supply voltage is 16 V, which allows the devices to be operated from a variety of rechargeable cells (±8 V
supplies down to ±1.35 V).
The CMOS inputs enable use in high-impedance sensor interfaces, with the lower voltage operation
making an attractive alternative for the TLC27x in battery-powered applications.
All members are available in PDIP and SOIC with the singles in the small SOT-23 package, duals in the
MSOP, and quads in the TSSOP package.
The 2.7-V operation makes it compatible with Li-Ion powered systems and the operating supply voltage
range of many micro power microcontrollers available today including TI’s MSP430.
2. FEATURES
◆ Rail-To-Rail Output
◆ Wide Bandwidth . . . 3 MHz
◆ High Slew Rate . . . 2 .4 V/µs
