MX610HD User’s Manual
MX610HD User’s Manual
1 x Backlight Locking Type Header
1 x SPI Header (2.54mm Pitch)
1 x I
2
C Header
1 x SMBus Header
1 x Front Audio Header with Shroud (2.54mm Pitch)
1 x Amplifier Locking Type Header (2.0mm Pitch)
1 x Front Panel Headers with Shroud (2.54mm Pitch)
1 x 8 bits GPIO Header with Shroud
1 x 4 Pin CPU Fan Header (4 Pin PWM)
1 x 4 Pin Chassis Fan Header (4 Pin PWM)
1 x Cable Type CMOS Battery
1 x Chassis Intrusion Locking Type Header
1 x 4 Pin Mini-Fit Jr DC-In Header
Mechanical & Environmental
Operating Temperature 0~60°C (32~140°F)
Operating Humidity 5%~90% relative humidity, non-condensing
Size (L x W) 6.7" (L) x 6.7" (W) (170mm x 170mm)
