BCM MX610HD - Front Audio Connector (FP_AUDIO1); Amplifier Connector (JAMP1)

MX610HD User’s Manual
MX610HD User’s Manual
39
1.7.10 Front Audio connector (FP_AUDIO1)
This connector is for a chassis-mounted front panel audio I/O module that supports either HD
Audio or legacy AC ‘97 (optional) audio standard.
FP_AUDIO1
9. LINE2L
7. SENSEB
5. LINE2R
3. MIC2R
1. MIC2L
10. LINE2-JD
8. NC
6. MIC2-JD
4. +3.3
2. GND
12
1.7.11 Amplifier Connector (JAMP1)
This connector allow user to connect an external audio amplifier.
JAMP1
1
1. AMP_L-
2. AMP_L+
3. AMP_R-
4. AMP_R+
