MX610HD User’s Manual
18 MX610HD User’s Manual
JCOMPWR1~3
COM1~3 power setting
2 x 3 header, pitch 2.00mm
JBKLVOL
LVDS panel power setting
1 x 3 header, pitch 2.00mm
JLVDS_BKL1 LVDS brightness mode setting 1 x 3 header, pitch 2.00mm
EDPPWR1 eDP power setting 1 x 3 header, pitch 2.00mm
Rear Panel Connector
Label
Function
Note
DC_IN1
DC in connector
USB34 USB 2.0 Type A connector Support 2 ports
DP1 Display port x1
HDMI1
HDMI port x1
LAN1
RJ-45 Ethernet Connector x 1
1 Gigabit Ethernet
LAN2 RJ-45 Ethernet Connector x 1 2.5 Gigabit Ethernet
USB12 USB 3.2 Type A connector Support 2 ports
LINEOUT1
Line out port x1
Color: Lime
MICIN1 Mic-in port x1 Color: Pink
Internal Connector
Label
Function
Note
CPU_FAN1 CPU Fan connector WAFER 1x4P, 2.54mm
CHA_FAN1
Chassis Fan connector
WAFER 1x4P, 2.54mm
F_PANEL1 Front Panel connector BOX header 2x5P, 2.54mm
ATX12V1 12V ATX power connectors PWR Conn 2x4P
COM1~3 Serial Port Connector Header 2x5P, 2.00mm
SATA1~2
SATA Connector
Male connector (Red)
FP_ AUDIO1 Front Panel Audio Connector BOX header 2x5P, 2.54mm
JDIO1 Digital I/O Connector WAFER 6x2P, 2.0mm
I2C1 I2C connector WAFER 4P, 2.00mm
USB56
Front USB 3.2 Header
BOX header 2x10P, 2.0mm
USB78 Front USB 2.0 Headers BOX header 2x5P, 2.54mm
LVDS1 LVDS header WAFER 2x20P, 1.25mm
JBKL1
LVDS backlight connector
WAFER 1x5P, 2.0mm
SMBUS1
SMBus connector
WAFER 1x5P, 2.0mm
JAMP1 Amplifier Connector WAFER 1x4P, 2.0mm
JCASE1 Chassis Intrusion Header WAFER 1x2P, 2.5mm
