Beacon MEGA - Wiring Schematics; Power Supply Module; Digital Display Module User-Assigned Signals; Digital Display Modules as Master Alarms

14
Part No. 6-847681-00 Rev. D
Typical wiring diagrams of master alarms for
the following systems are provided:
1Bulk Oxygen System with Reserve
2Nitrous Oxide Manifold System without
Reserve
3 Duplex Medical Air Compressor
4Nitrogen Manifold System without Reserve
5Duplex Vacuum Pump System
The following wiring schematics are provided.
If you have any questions, please call Beacon
Medical Products Technical Support at 1-800-676-
1115.
1. Power Supply Module
2. Sensor Module to Digital Display Module
3. Digital Display Module User-Assigned Signals
4. Remote Pressure/Vacuum Transmission
5. Digital Display Modules As Master Alarms
6. Multi-Signal Alarm Module
7. Computer Interface Relay Module
8. External Signal Relay
9. Remote Pressure/Vacuum Switches
10. MEGA Network
Wiring Schematics
Typical Master Alarm Wiring
Wiring Installation
