6
Part No. 6-847681-00 Rev. D
Alarms ordered as separate modules are
assembled on-site.
1. Carefully open the carton(s) and verify
contents.
Refer to diagrams on pages 49-51.
Power Supply Module
•Instructions
Rough-in components:
•Mounting box with dust cover
•(2) End panels
•(2) Grommets
•(4) Screws, #6-20 x 1/4
Finish components:
•Power supply module chassis
•Trim plate
•Cover plate
•(4) Screws, #6-32 x 9/16
•(2) Screws, #6-32 x 3/4
Gas ID and location labels
Digital Display Module
Rough-in components:
•Mounting box with dust cover
Interconnect board
•(4) Screws, #6-20 x 1/4
Finish components:
•Digital display module chassis
•Cover plate
•(2) Screws, #6-32 x 1-1/2
•System status labels
Field Assembled Alarm Panels
Unpacking
Sensor Module
Rough-in components:
•Mounting box with dust cover
•(2) End panels
Gas/vacuum service rough-in
•(8) Screws, #6-20 x 1/4
Finish components:
•Sensor
•Trim plate
•Cover plate
•(2) Screws, #6-32 x 1-1/2
Multi-Signal Alarm Module
Rough-in components:
•Mounting box with dust cover
Interconnect board
•(4) Screws, #6-20 x 1/4
Finish components:
•Multi-signal alarm module chassis
•Cover plate
•(2) Screws, #6-32 x 1-1/2
•System status labels
Computer Interface Relay Module
Rough-in components:
•Mounting box with dust cover
Interconnect board
•(4) Screws, #6-20 x 1/4
Finish components:
•Trim plate
•Cover plate
•(2) Screws, #6-32 x 1-1/2
2. Store the finish components in a safe
place for installation after the walls are
finished.
3. Proceed to Rough-In Installation.
