Part No. 6-847681-00 Rev. D
Introduction
Definitions
Unpacking
Area Alarm Panel
Alarm panel which monitors the medical gas
and vacuum systems serving a specific area.
Dry-Contact
An electrical contact that is isolated or
unconnected from any electrical source.
LCD
Liquid Crystal Display
LED
Light Emitting Diode
Master Alarm Panel
Alarm panel which monitors the medical gas
and vacuum sources.
Alarm panels ordered under the APL,
APR, MPL and MPR part number series are
preassembled at the factory.
1. Carefully open the carton and verify
contents.
APL or MPL
•Factory preassembled rough-in
•Carton(s) of finish components
•Instructions
APR or MPR
•Factory preassembled rough-in
•Carton(s) of finish components
•Carton(s) of remote sensors
•Instructions
2. Remove finish components carton(s).
3. Write the alarm panel location on the
finish component carton(s).
4. Store the finish components carton(s) in
a safe place for installation after the walls
are finished.
5. Proceed to Rough-In Installation.
Factory Preassembled Alarm Panels
Alarm Configurations
APL
Area alarm panel with local sensors. The
sensor modules are mounted directly above
the corresponding digital display modules.
APR
Area alarm panel with remote sensors. The
sensor modules are located up to 5000 ft
from the alarm panel.
MPL
Master alarm panel with local sensors. The
sensor modules are mounted directly above
the corresponding digital display modules.
MPR
Master alarm panel with remote sensors.
The sensor modules or switches are located
up to 5000 ft from the alarm panel.
