2.2 DK50 Development Board Start-up (SC13)
2.2.1 What do we need to get started?
• The DK51 Development Kit consisting of:
• DK50 Development Board
• Embedded Web Controller SC13 (on the DK50)
• Power supply unit
• Null-modem cable
• Borland C++ Software Development Environment
• A PC running Windows 95/98/NT/2000/XP, with an Ethernet network interface
• Serial port on your PC
• Ethernet network with an available twisted pair connection for the DK50 Development Board
• Windows HyperTerminal program
• Optional: Compact Flash Card, if you want to configure the CF Interface (not needed for start-up)
• Zip-files from the Beck Getting Started web site:
• FTP client TotalCommander as shareware
• CHIPTOOL Software
• DK50 Online demo software package
• Compact Flash Card Driver EXTIDE.EXE
The Getting Started web site contains all the tools and programs required to put the Development Kit
into operation. The FTP client is a shareware program. For more details please read the online
documentation of this tool. You can use any FTP program which provides file transfer support.
Be aware, that the Embedded Controller SC13 and DK50 Development
Board are Electrostatic Sensitive Devices. Observe general precautions
for handling.
