IPC@CHIP DK41 / DK51
Getting Started V2.2
© 2000-2004 Beck IPC GmbH Page 29 of 61
2.3 DK50 Development Board Start-up (SC11)
The DK51 Development Kit can also be used in conjunction with an SC11. The SC11 is the same as
the SC13 apart from the fact that it does not have an Ethernet network interface. It is therefore
commissioned differently to the SC13 and is described here separately.
2.3.1 What do we need to get started?
• DK50 Development Board
• Embedded Web Controller SC11 (on the DK50)
• Power supply unit PSE10
• Null-modem cable ZK14
• A PC running Windows 95/98/NT/2000/XP
• Serial port on your PC
• Windows HyperTerminal program
• Optional: Compact Flash Card, if you want to configure the CF Interface (not needed for start-up)
• Zip-files from the Beck Getting Started web site:
• FTP client TotalCommander as shareware
• CHIPTOOL Software
• DK50 Online demo software package
• Compact Flash Card Driver EXTIDE.EXE
The Getting Started web site contains all the tools and programs required to put the Development Kit
into operation. The FTP client is a shareware program. For more details please read the online
documentation of this tool. You can use any FTP program which provides file transfer support.
Be aware, that the Embedded Controller SC13 and DK50 Development
Board are Electrostatic Sensitive Devices. Observe general precautions
for handling.
