2.1.4 Step 3 – Setting up the Ethernet communication
The following chapter describes the set-up of the Ethernet communication. Before moving on, you
must decide if you want to use either DHCP
1
or fixed addressing. With DHCP, the IPC@CHIP
retrieves a valid IP configuration from a DHCP server. With fixed addressing, you define the IP
address, network mask and an optional gateway
2
.
The default configuration for the IPC@CHIP is DHCP since this will ensure that the IPC@CHIP adapts
to an existing network if this network has a DHCP server. If you do not have a DHCP server, the
IPC@CHIP will not disturb the operation of your network. We cannot ship with a fixed IP configuration
since we have no knowledge of your network configuration.
a) DHCP IP configuration: (default setting)
In a network supporting DHCP the DK40 retrieves a valid IP configuration from a DHCP server
automatically.
Connect the DK40 to your Ethernet network hub or switch with a standard twisted pair cable. Reset
your DK40 with power off and power on. On the terminal window (HyperTerminal) you will see the
output from the start-up procedure. Here you will see the serial number, @CHIP-RTOS version, build
date and other start-up information. If an IP configuration could be successfully received from the
DHCP server, this IP configuration will be displayed at the end of the start-up output messages. In the
event of an error, the message “DHCP request failed” will be output after a timeout of several seconds.
@CHIP-RTOS
Copyright (c) BECK IPC GmbH 1999-2004
Copyright (c) Elmic Systems, Inc. 1999-2004
Target=SC12 Serialnumber=020C2
Bootstrap version V2.24
@CHIP-RTOS version SC12 V1.10 LARGE
Build: Mar 22 2004
Serial EXT Port using DMA receive, IRQ send
Serial COM Port using DMA receive, IRQ send
Starting TCPIP
Init network
Ethernet packet interface
Config server
FTP server
Web server
Telnet server
Ext. disk interface.
TCPIP device driver API
Software SPI API
@CHIP-RTOS boot successfully finished
Leased IP 172.30.11.228
Mask 255.255.240.0
Gateway 172.30.0.2
Leasing time: 3600 secs
1
DHCP: "Dynamic Host Configuration Protocol“.
2
Gateway: "Computers that interconnect two networks and pass packets from one to the other are called internet gateways or
internet routers."
