Product overview
EL6752 13Version: 2.1
2.2 Technical data
Technical data EL6752-0000 EL6752-0010
Bus system DeviceNet
Variante Master Slave
Number of fieldbus channels 1
Data transfer rate 125, 250 or 500 kbaud
Bus interface Open style 5-pin connector according to DeviceNet specification,
galvanically isolated; card comes with connector.
Bus devices maximum 63 slaves
Communication DeviceNet network master
(scanner)
DeviceNet - slave
Diagnostics Status LEDs
Power supply via the E-bus
Current consumption via E-bus typ. 260 mA
Electrical isolation 500 V (E-bus/CANopen)
Configuration with TwinCAT System Manager
Weight approx. 70 g
Permissible ambient temperature range
during operation
-25°C ... +60°C (extended temperature range)
0°C ... +55°C (according to cULus [}97] for Canada and the
USA)
0°C ... +55°C (according to ATEX [}27], see special conditions
[}27])
Permissible ambient temperature range
during storage
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 26 mm x 100 mm x 52 mm
Mounting [}15]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
ATEX [}27]
cULus [}97]
