Function blocks
Function blocks for TwinSAFE logic components 183
3.26.5.4 Scope recording of the sequence
Figure 3-121: ScopeView display of the signal sequence
Color
Signal description
FB input CamReset (rising and falling edge before a motion may start)
OverrunCAM (FB input)
UpwardCAM (FB input)
TDC (FB output; here position 64535 to 100)
BDC (FB output; here position 31767 to 33767)
Upwards (FB output)
Current press position. Here one revolution: 0 to 65535 increments
OverrunTDC output. Change in position after TDC1_LowerLimit is reached.
