Installation GRS105/GRS106
Release
01
11/2021
23
5.3.3 Rear views
6 Port group II 8 × RJ45 socket for 100/1000/2500 Mbit/s Twisted pair connections
7 Port group III 16 × RJ45 socket for 10/100/1000 Mbit/s Twisted pair connections
8 MAC address field
9 Oblong hole
10 Mounting bracket
11 Port group I 6 × SFP slot for 1/2.5/10 Gbit/s F/O connections
12 Management interface (MGMT), USB Type-C socket
13 SD card slot (ACA31)
Table 4: Rear views: Power supply characteristic value G9 (non-redundant,
1 connector) and GG (redundant, 2 connectors)
Table 5: Rear views: Power supply characteristic value M9 (non-redundant,
1 connector) and MM (redundant, 2 connectors)
Table 6: Rear views: Power supply characteristic value L9 (non-redundant,
1 connector) and LL (redundant, 2 connectors)
Table 3: Front view device variant GRS106-6F8T16T...
