Installation GRS105/GRS106
Release
01
11/2021
61
13 Technical data
13.1 General technical data
13.2 Supply voltage
Dimensions See “Dimension drawings” on page 64.
Weight GRS105/GRS106 with
1 Power supply unit
4.7 kg (10.36 lb)
GRS105/GRS106 with
2 Power supply units
5.1 kg (11.24 lb)
Pollution degree 2
Protection classes Laser protection Class 1 according to IEC 60825-1
Degree of protection IP30
Ground connection Screw type M3
Tightening torque 0.34 Nm (3 lb-in)
Minimum conductor diameter 0.75 mm² (AWG18)
Table 16: General technical data
Power supply unit with
supply voltage
characteristic value G
Nominal voltage 110 V AC ... 240 V AC, 50 Hz ... 60 Hz
Voltage range incl.
maximum tolerances
88 V AC ... 276 V AC
Connection type Built-in non-heating-appliance connection
(built-in C14 plug according to IEC 60320-1)
Minimum conductor
diameter
0.75 mm² (AWG18)
Maximum conductor
diameter
2.5 mm² (AWG12)
Power loss buffer 110 V AC: >26 ms
230 V AC: >140 ms
Back-up fuse for each
voltage input
Nominal rating:
Characteristic:
20 A
slow blow
Overload current
protection on the device
Non-replaceable fuse
Peak inrush current <5 A
Table 17: Supply voltage
