15.3 Gigabit Ethernet SFP transceiver
Product code Mode
a
Wave length Fiber System
attenuation
Example for F/O line
length
b
Fiber attenuation BLP/Dispersion
M-SFP-SX/LC... MM 850 nm 50/125 µm 0 dB ... 7.5 dB 0 km ... 0.55 km
(0 mi ... 0.34 mi)
3.0 dB/km 400 MHz×km
M-SFP-SX/LC... MM 850 nm 62.5/125 µm 0 dB ... 7.5 dB 0 km ... 0.275 km
(0 mi ... 0.17 mi)
3.2 dB/km 200 MHz×km
M-SFP-MX/LC... MM 1310 nm 50/125 µm 0 dB ... 12 dB 0 km ... 1.5 km
(0 mi ... 0.93 mi)
1.0 dB/km 800 MHz×km
M-SFP-MX/LC... MM 1310 nm 62.5/125 µm 0 dB ... 12 dB 0 km ... 50 km
(0 mi ... 31.06 mi)
1.0 dB/km 500 MHz×km
M-SFP-LX/LC... MM 1310 nm
c
50/125 µm 0 dB ... 10.5 dB 0 km ... 0.55 km
(0 mi ... 0.34 mi)
1.0 dB/km 800 MHz×km
M-SFP-LX/LC... MM 1310 nm
d
62.5/125 µm 0 dB ... 10.5 dB 0 km ... 0.55 km
(0 mi ... 0.34 mi)
1.0 dB/km 500 MHz×km
M-SFP-LX/LC... SM 1310 nm 9/125 µm 0 dB ... 10.5 dB 0 km ... 20 km
(0 mi ... 12.43 mi)
e
0.4 dB/km 3.5 ps/(nm×km)
M-SFP-LX+/LC... SM 1310 nm 9/125 µm 5 dB ... 20 dB 14 km ... 42 km
(8.70 mi ... 26.10 mi)
0.4 dB/km 3.5 ps/(nm×km)
M-SFP-LH/LC... LH 1550 nm 9/125 µm 5 dB ... 22 dB 23 km ... 80 km
(14.29 mi ... 49.71 mi)
0.25 dB/km 19 ps/(nm×km)
M-SFP-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 71 km ... 108 km
(44.12 mi ... 67.11 mi)
0.25 dB/km 19 ps/(nm×km)
M-SFP-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 71 km ... 128 km
(44.12 mi ... 79.54 mi)
0.21 dB/km (typically) 19 ps/(nm×km)
M-SFP-LH+/LC EEC LH 1550 nm 9/125 µm 13 dB ... 32 dB 62 km ... 116 km
(38.52 mi ... 72.07 mi)
0.25 dB/km 19 ps/(nm×km)
M-SFP-LH+/LC EEC LH 1550 nm 9/125 µm 13 dB ... 32 dB 62 km ... 138 km
(38.52 mi ... 85.75 mi)
0.21 dB/km (typically) 19 ps/(nm×km)
Table 27: F/O port 1000BASE-FX (SFP fiber optic Gigabit Ethernet Transceiver)
