Installation OCTOPUS 8TX-EEC
Release
07
01/2021
39
Parameter Values Default values Comment
global Aging time Aging time in s 300 s Value range 0 ... 1048575
QoS 802.1p mapping VLAN Priority 0 ... 7
Traffic Class 0 ... 3
VLAN Priority
0
1
2
3
4
5
6
7
Traffic Class
1
0
0
1
2
2
3
3
QoS DSCP mapping DSCP value 0 ... 63
Traffic Class 0 ... 3
See table 2 on page 40.
QoS Trust Mode untrusted, trustDot1p, trustIpDscp trustDot1p This also includes VLAN 0 mode for
Profinet applications.
per port Flow control enabled / disabled disabled
Port admin state enabled / disabled enabled
Jumbo frames enabled / disabled disabled Globally enabled if at least one port is
enabled
Broadcast storm protection enabled / disabled disabled Ingress rate limiter
Broadcast storm threshold 0% ... 100% 100%
Multicast storm protection enabled / disabled disabled Ingress rate limiter
Multicast storm threshold 0% ... 100% 100%
Link alarm enabled / disabled disabled
per TP port Autonegotiation enabled / disabled enabled
Speed 100 Mbit/s, 10 Mbit/s 100 Mbit/s Only if autonegotiation is disabled
Duplex mode FDX / HDX FDX Only if autonegotiation is disabled
Autocrossing enabled / disabled enabled Only if autonegotiation is disabled
MDI state MDI, MDI-X MDI-X Only if autonegotiation and
autocrossing is disabled
Table 1: Configuration parameters
