Installation OCTOPUS 8TX-EEC
Release
07
01/2021
47
7 Technical data
7.1 General technical data
Dimensions
W × D × H
OCTOPUS 8TX-EEC 2.40 in × 1.22 in × 7.91 in
(61 mm × 31 mm × 201 mm)
OCTOPUS 8TX PoE-EEC 2.40 in × 1.81 in × 7.91 in
(61 mm × 46 mm × 201 mm)
OCTOPUS 8TX-EEC-M 2.40 in × 1.81 in × 7.91 in
(61 mm × 46 mm × 201 mm)
Weight OCTOPUS 8TX-EEC 1.1 lb (0.5 kg)
OCTOPUS 8TX PoE-EEC 2 lb (0.9 kg)
OCTOPUS 8TX-EEC-M 2 lb (0.9 kg)
Power supply
OCTOPUS 8TX-EEC
Safety extra-low voltage (SELV)
Relevant for North America: NEC Class 2 power source max. 2 A.
Rated voltage DC: 12/24/36 V DC
Voltage range DC incl.
maximum tolerances:
9.6 V DC ... 45 V DC
Connection type 5-pin, “A”-coded M12 connector
Power loss buffer >10 ms
Back-up fuse for each voltage
input when supplied via 1 input
Nominal rating:
Characteristic:
1 A ... 4 A
slow blow
Back-up fuse for each voltage
input when supply is via 2
inputs
Nominal rating:
Characteristic:
1 A ... 2 A
slow blow
Peak inrush current <1.4 A (1ms)
Current integral I²t 0.15 A
2
s
Power supply
OCTOPUS 8TX PoE-
EEC
Rated voltage DC: 24 V DC
Voltage range DC incl.
maximum tolerances:
16.8 V DC ... 32 V DC
Connection type 5-pin, “A”-coded M12 connector
Power loss buffer >10 ms during data transmission; no
power loss buffer for PoE
Back-up fuse for each voltage
input when supplied via 1 input
Nominal rating:
Characteristic:
3.5 A ... 4 A
slow blow
Back-up fuse for each voltage
input when supply is via 2
inputs
Nominal rating:
Characteristic:
3.5 A ... 4 A
slow blow
Peak inrush current <5 A (1 ms)
Current integral I²t 0,22 A
2
s
