Installation OCTOPUS 8TX-EEC
Release 07 01/2021
53
7.5 Power consumption/power output
7.6 Signal contact
This applies to the following device variants only:
 OCTOPUS 8TX-EEC-M
Name Maximum power consumption power output
OCTOPUS 8TX-EEC 4.2 W 14.3 Btu (IT)/h
OCTOPUS 8TX PoE-EEC 44 W 47.8 Btu (IT)/h
OCTOPUS 8TX-EEC-M 6 W 20.0 Btu (IT)/h
Signal contact
Connection type 5-pin, “A”-coded M12 plug
Tightening torque 4.5 lb-in (0.51 Nm)
Nominal value I
max
=1A at U
max
= 30 V AC (resistive load)
I
max
=1A at U
max
= 60 V DC (resistive load)
Table 4: Signal contact: OCTOPUS 8TX-EEC-M
