54
Installation OCTOPUS 8TX-EEC
Release
07
01/2021
8 Scope of delivery, order numbers and
accessories
Scope of delivery
Note: The connector ELWIKA 5012 PG7 (933 175-100) supports a
temperature range from -13 °F to +158 °F (-25 °C to +70 °C). It may thus
limit the application range of the overall system.
You can obtain special sockets for the total temperature range and with
the degree of protection IP65/67 and on request.
Order number
Accessories
Note that products recommended as accessories may have different
characteristics to those of the device, which may limit the application
range of the overall system. For example, if you add an accessory with
IP20 to a device with IP67, the IP of the overall system is reduced to IP20.
Note: To sustain the IP65/67 suitability for your device, use the
accessories with IP65/67 properties exclusively.
Device Scope of delivery
OCTOPUS 8TX-EEC
OCTOPUS 8TX PoE-EEC
OCTOPUS 8TX-EEC-M
Device
1 × Transport protection cap for supply
voltage connection
7 × Protection screws for M12 socket,
plastic
15 × Indicator plates
ELWIKA 5012 PG7 connector
(5-pin M12 socket for power supply)
Safety and general information sheet
Device Order number
OCTOPUS 8TX-EEC 942 150-001
OCTOPUS 8TX PoE-EEC 942 151-001
OCTOPUS 8TX-EEC-M-2S 942 301-001
OCTOPUS 8TX-EEC-M-2A 942 301-002
Name Order number
AutoConfiguration Adapter ACA21-M12 (EEC) 943 913-003
AutoConfiguration Adapter ACA22-M12 (EEC) 942 125-001
AutoConfiguration Adapter ACA22-M12-C (EEC) 942 306-001
M12 connector, 4-pin, “D”-coded 934 445-001
M12-USB adapter cable (for connecting the ACA with a computer) 942 199-001
Adapter cable M12 5-pin male to USB (for configuration of OCTOPUS 8TX-
EEC-M devices)
942 309-001
