Belden Hirschmann OCTOPUS 8TX PoE-EEC - Dimension Drawings

Installation OCTOPUS 8TX-EEC
Release 07 01/2021
49
7.2 Dimension drawings
Figure 11: OCTOPUS 8TX-EEC
60,7
2.4
6
0.24
4,5
4,5 0.2
6
0.24
191,3
7.5
0.2
M4
x
y
8
7
6
5
4
3
2
1
L/D
L/D
L/D
L/D
P2
P1
ACAPOWER
IP67 ETHERNET Switch
OCTOPUS 8TX-EEC
mm
inch
20,4
0.8
18
0.71
13
0.51
200,5
7.9
POWER
Pin Function
1
2
3
4
5
P1+
N.C.
P-
P2+
N.C.
5
3
4
2
1
TP - Ports
Pin Function
1
2
3
4
TD+
RD+
TD-
RD-
3
4
21
I in: 0,35 - 0,11A
Uin: 12 - 36V
+
CLASS 2
DOM:WW/ YYYY
S/N: v1
Made in Germany
Hirschmann Automation
and Control GmbH Stuttgarter Str. 45-51
72654 Neckartenzlingen Germany
WARNING- EXPLOSION HAZARD do not disconnect in Haz.Loc
Avertissement- RISQUE D'EXPLOSION ne pas deconnector dans Haz.Loc
lnd. Cont Eq. for Use in Haz.Loc.
E203960
Also Listed as
IND.CONT.EQ
E175531
/
|
A
e
j
ä
IEC 61131-2
FCC CLASS A
E1 10 R - 05 8148
