BHT-430-MM-2
5-00-00
26 JAN 2007 Rev. 15 Page 65
CAUTION
THE INGESTION OF BROKEN INLET SCREEN
SEGMENTS CAN CAUSE FOREIGN OBJECT
DAMAGE TO THE ENGINE COMPRESSOR
SECTION.
Chapter 71 14. Examine both of the engine inlet screens for damage. (F5/
F6)
Chapter 71 15. Examine all of the firewalls and fire shields for cracks,
distortion, loose or missing rivets, broken spot welds and
deterioration of the seals and sealant. (E1/E2)
Chapter 71 16. Examine the left power plant area for fuel or oil leaks.
Examine the wire harness and the flexible and rigid fuel and oil
lines for wear, chafing and damage. Make sure they are
correctly attached. (E1)
Chapter 71 17. Examine the left engine mounts and accessories for
damage. Make sure they are correctly attached. (E1)
Chapter 76 18. Examine the left engine power lever, fuel control box
assembly and control cable for looseness and correct range of
motion. Make sure they are correctly attached. (E1)
Chapter 63 19. Examine the left oil cooler blower driveshaft and couplings
for damage. Make sure they are correctly attached. Examine
the discs for cracks that radiate from the bolt holes, corrosion,
wrinkles or other signs of overstress. (E1)
Chapter 79 and
BHT-430-CR&O-V.2
20. Examine the left oil cooler blower for blockage, cleanliness
and damage. Make sure it is correctly attached. (E1)
Chapter 71 21. Examine the right power plant area for fuel or oil leaks.
Examine the flexible and rigid fuel and oil lines for wear, chafing
and damage. Make sure they are correctly attached. (E2)
Chapter 71 22. Examine the right engine mounts and accessories for
damage. Make sure they are correctly attached. (E2)
SCHEDULED INSPECTIONS
5-24. PROGRESSIVE INSPECTION — EVENT 9 (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
