Bend-Tech Dragon A400 - Parts and Equipment; Powered Gate Overview; Equipment and Parts Required

10 Bend-Tech Dragon A400
Powered Gate Retrot Guide
Parts and Equipment
01
01
Overview
Powered Gate Overview
The Dragon A400 Powered Gate allows the machine to process angle and channel material in
addition to round, square and rectangle material. Bend-Tech has found that to process angle
or channel material it is required that the Gate move in coordination with the Chuck. Without
a Powered Gate, angle or channel material cannot be held securely in the Gate. Customers
who want to process angle or channel material can purchase a new Dragon A400 machine

This guide is intended to instruct the Customer regarding the installation of the Dragon A400

Equipment and Parts Required
• Cordless drill
• 
• 
• Ratchet
• 12 in. socket extension
• 17mm socket
• ¼ in. Allen wrench
• 
• 
Powered Gate Retrot Kit
• C-Drive Control Box (1)
• C-Drive Motor Cable (1)
• C-Drive Homing Sensor Cable (1)
• Stainless Gate Rollers (4)
• Gate Mount Plate (1)
• Gate Ring Gear (1)
• C-Axis Motor Mount (1)
• C-Axis Motor (1)
• C-Axis Drive Gear (1)
