13Bend-Tech Dragon A400
Powered Gate Retrot Guide
Installation Guide
02
1. Breakout Board
Locate the Control Box mounted on the rear of the third Rail Support Leg. Locate the
blade screwdriver, turn the latch
counterclockwise to open the Control
Box.
Locate the red Breakout Board in the
upper left hand side of the Control
Box. The Breakout Board will have a
Drivers. This will give access to the
left hand Control Box Mounting Bolt.
The Breakout Board should remain
2.Control Box Mounting Bolts
Control Box Mounting Bolt heads are
located inside the Control Box, in the
upper right and left hand corners of
the Control Box. Use a ratchet with a
heads inside the Control Box. Place
the backside of the Control Box. Hold
the nut with the wrench and turn the
ratchet counterclockwise to remove the
Mounting Bolt. Repeat this process for
the right side Mounting Bolt. Once the
mounting bolts are removed, position
the old Control box out of the way so
the new Control Box can be mounted.
Leave all connections on the old Control
Box. Connections will be transferred to
the new Control Box later in the process.
Hold the Breakout Board on
the motor drivers.
Motor Divers
Control Box Mounting Bolts
To Next Page
