20 Bend-Tech Dragon A400
Powered Gate Retrot Guide
Installation Guide
02
Note
close the Gate using the Vertical Gate Lead Screw. This aids in handling of the
Gate during the installation process.
4. Gate Bearing Rotation Plate
At the rear of the Gate Mount assembly,
place a 17mm socket and ratchet on the
v-groove eccentric bearing nut. Using the
thin wrench supplied with the Powered
back of the v-groove eccentric bearing.
Using the ¾ in. wrench to prevent the
v-groove eccentric bearing from rotating,
use a ratchet and 17mm socket to remove
the mounting nut for the v-groove eccentric
bearing.
Lifting the Gate Bearing Rotation Plate and
v-groove eccentric bearing at the same
bearings from the Gate Mount Plate and set aside with the v-groove eccentric bearing. The
Installer will be re-using the v-groove bearings. The Installer will not be re-using the Gate
Mount Plate or the Gate Bearing Rotation Plate.
Important
v-groove bearings.
V-Groove
Eccentric Bearing
Fixed V-Groove
Bearings
To Next Page
