Bender A-ISOMETER IRDH375 - Page 57

57
Characteristic curves
Current output 0 - 20 mA option B
Current output 4 - 20 mA option B
1,00
10,00
100,00
1000,00
10000,00
0,0 5,0 10,0 15,0 20,0 25,0
I[mA]
Rf[KOhm]
1,00
10,00
100,00
1000,00
10000,00
0,0 5,0 10,0 15,0 20,0 25,0
I[mA]
Rf[KOhm]
Rf = insulation fault in kΩ
I = current output in mA
Rf = insulation fault in kΩ
I = current output in mA
