Bender A-ISOMETER IRDH375 - Response Values Alarm1 and Alarm2; Operating Principle of the Alarm Relays; Memory Setting; Current Output

35
Operation and setting
Response values Alarm1 and Alarm2
The response values Alarm1 and Alarm2 are set with the arrow keys
TEST RESET
and
stored with the ENTER key
MENU
.
Operating principle of the alarm relays
K1 : NC = N/C operation contacts 11-12-14
(the alarm relay is in fail-safe mode)
K1 : NO = N/O operation contacts 11-12-14
(the alarm relay is deenergized during normal operation)
K1 : Flash = fl ashing function contacts 11-12-14
(the alarm relay and the LED fl ash in the event of an alarm
message approx. 0.5 Hz)
K2 : NC = N/C operation contacts 21-22-24
(the alarm relay is in fail-safe mode)
K2 : NO = N/O operation contacts 21-22-24
(the alarm relay is deenergized during normal operation)
K2 : Flash = fl ashing function contacts 21-22-24
(the alarm relay and the LED fl ash in the event of an
alarm message approx. 0.5 Hz)
Memory setting
Memory: on = Fault memory is activated
Reset the device using the reset button after clearing the
fault.
Memory: off = Fault memory deactivated (factory setting)
Current output
The current output of the IRDH375B can be set to „0-20 mA“ or „4-20 mA“via
the submenu „M+/M-:“. The maximum load is 500 Ohm.
Function 0-20 mA:
Rf= insulation fault, I= current in mA
Function 4-20 mA:
Rf= insulation fault, I= current in mA
B
B
B
B
B
B
R
f
=
20 mA x 120 kOhm
I
- 120 kOhm
R
f
=
16 mA x 120 kOhm
I - 4 mA
- 120 kOhm
