CommissioningCommissioning
iso685-D-P_D00170_00_M_XXDE/06.2016
33
7.2 Initial commissioning
Follow the instructions of the commissioning wizard on the display.
7.2.1 Set language
The language selected here will be used in the menu and for device messages.
7.2.2 Set time and date
Alarm messages in the history memory and the insulation resistance value over time can
only be assigned correctly to the isoGraph when the date and time are set correctly.
Check network function!
When the device has been integrated into a network, the influence on the
network has to be checked with the device switched on and off.
Language
6.6.2
• Deutsch
o English
o ...
Date 5.2.4
14.01.2 014
min. 1
max. 31
Commissioning 6.6
2/9
Please set the
current date
and time.
7.2.3 Setting system type
By setting the system type the insulation monitoring device can be optimally adapted to
the system to be monitored. The system type is essential information for the insulation
monitoring device in order to determine the insulation resistance correctly.
7.2.4 Set profile
In order to optimally adapt the insulation monitoring device to the system to be moni-
tored, select a profile here that suits your system. For an overview of the profiles refer to
“Device profiles” on page 73. The profile "Power circuits" is suitable for most IT systems.
7.2.5 Setting EDS mode
Set the mode for the insulation fault location to manual, automatic or 1 cycle.
For further information, refer to “Mode” on page 52.
6.6.6
• DC
o AC
o 3AC
System type
6.6
5/11
Commissioning
Please choose the
type of system
that best suits
your installation.
6.6.7
Profile
• Power circuits
o Control circuits
o Generator
o High capacitance
o Inverter>10 Hz
o Inverter<10 Hz
Commissioning 5.6
Please select a
profile that suits
your application.
7/9
Mode
• manual
o auto
o 1 cycle
6.6.8
Commissioning 6.6
Please select the
EDS mode.
7/11
