Bender ISOMETER iso685-D-P User Manual

DisplayDisplay
iso685-D-P_D00170_00_M_XXDE/06.2016
37
8.3 Fault display (inactive)
An inactive fault is displayed by . If several faults have occurred, the number of faults
will also be indicated.
The message shown on the display below means that there has been a fault in the past
but the device is no longer in fault condition.
230 kΩ
IT System
3x
1/4
230 kΩ
PGH ON
If several fault messages have appeared, you can navigate through the faults using the
and buttons. In addition to the type of fault and the associated alarm value, you can
see when the fault has occurred and for how long it has been active.
7 kΩ
Insulation fault
28.0 3.14 17:02
28.0 3.14 17:18
2/4
7 kΩ
PGH ON
