Page #78 background imageLoading...
Page #78 background image
iso685-D-P_D00170_00_M_XXDE/06.2016
78
16. Alarm messages
16.1 Alarm messages of the ISOMETER®
Alarm message Description Measures Reference LED indicators
Insulation fault
An insulation fault exists. The insulation resistance falls
below the response value R
an1
.
Observe insulation resistance in the monitored system and, if nec-
essary, eliminate fault.
Reset fault message by pressing the reset button
“Function descrip-
tion” on page 12
ALARM 1 lights
Insulation fault
An insulation fault exists. The insulation resistance falls
below the response value R
an2
.
If necessary, locate insulation fault using the EDS
Eliminate insulation fault in the system being monitored
Reset fault message by pressing the reset button
“Function descrip-
tion” on page 12
ALARM 2 lights
Check L1-L2-L3 for cor-
rect connection!
No low-resistance connection between the line con-
ductors
Check the wiring of terminals L1/+, L2 and L3/- to the IT system
Press the test button
Check mains voltage
•Check fuses
Check set system type
“Connection” on
page 20
& menu setting
“System type” on
page 45
ALARM 1 + ALARM
2 flash alternately
Check E-KE connections
for interruptions!
No low-resistance connection between terminals E and
KE to earth (PE)
Check the wiring of terminals E and KE to earth (PE)
Press the test button
“Connection” on
page 20
ALARM 1 + ALARM
2 flash in common
mode
Service mode active! The device is in maintenance condition Contact Bender Service SERVICE lights up
The profile does not suit
the application!
Wrong profile selected for this application
Check measured system capacitance or mains frequency in the
Info menu
Select another profile taking into consideration the characteristics
“Device profiles” on
page 73 &
“Profile” on page 45
No DHCP server found! Connection problem at the Ethernet interface
Check cable connection at the Ethernet interface
Check the DHCP server's availability
Check the DHCP's interface configuration in the device
“DHCP” on page 61
Check time and date! Time and date have not been set yet
Set local time and date
(in case of voltage failure a buffer for three days)
“Clock” on page 60
Load on X1 too high! Sum of the external loads on X1 is too high
Check load at X1.+, X1.Q1 and X1.Q2
Check ambient temperature
Device error x.xx Internal device fault
Press the TEST button
Switch the supply voltage off and on
•Contact Bender Service
SERVICE lights up
Num.ISOnet devices
The configured number of devices does not match the
number of devices that are actually included in the
ISOnet interconnection.
•Check settings
Check Ethernet connection
“System isolation via
ISOnet” on page 71
