Bender ISOMETER iso685-D-P User Manual

Alarm messages
iso685-D-P_D00170_00_M_XXDE/06.2016
79
Failure address
One device of the
ISOnet interconnection is not accessible
• Check Ethernet connection
• Check device function
“System isolation via
ISOnet” on page 71
Disturbance ISOnet
General fault at ISOnet, which is not covered by
"Num.ISOnet devices" and "Failure address". For exam-
ple, sending messages can fail or another device can-
not process a message.
• Check Ethernet connection
• Check device function
“System isolation via
ISOnet” on page 71
Start search for EDS
channels now?
A device on the BS bus has failed or cannot be
detected. The ISOMETER® searches automatically for
channels.
• Test wiring of terminals A, B to X1 of all devices
• Start search for EDS channels now
“BS bus” on page 68
and “Scanning
channels” on
page 52
Malfunction overcurrent
The locating current for the insulation fault location is
higher than the set limit value. The insulation fault loca-
tion is aborted and the insulation resistance measure-
ment is continued even if an insulation fault is still
active. The insulation fault location is only restarted
when the alarm message has been reset and there still
exists an insulation fault.
• Reset fault message by pressing the RESET button
• If the fault does not disappear after pressing the RESET button, the
device is defective. In this case, contact Bender Service.
“Current” on page 51
Overtemperature PGH
The locating current injector in the ISOMETER® has
heated up. The ISOMETER® stops the locating current
injector until it cools down and then restarts it.
• If necessary, reduce the maximum locating current
• Contact Bender Service if the fault does not disappear or occurs
more frequently
“Setting EDS cur-
rent” on page 34
DC offset voltage There is a DC offset voltage in the system. • Check insulation fault and eliminate fault of DC components.
“DC alarm” on
page 44
Undervoltage Operating outside the specified supply voltage range • Check supply voltage
Overvoltage Operating outside the specified supply voltage range • Check supply voltage
Alarm message Description Measures Reference LED indicators
