Bender ISOMETER iso685-D-P User Manual

SettingsSettings
iso685-D-P_D00170_00_M_XXDE/06.2016
63
10.2 Factory settings
Parameter Value
Response values/alarms
Response value R
an1
(ALARM 1)
40 kΩ
Response value R
an2
(ALARM 2)
10 kΩ
DC alarm off
DC-offset voltage for DC alarm 65 V
Fault memory off
Coupling monitoring on
Time response
Start-up delay T
start-up
≤ 0 s
Digital inputs
Digital input 1
Mode (Operating mode) Active high
Function Test
Digital input 2
Mode (Operating mode) Active low
Function Reset
Digital input 3
Mode (Operating mode) Active high
Function Deactivate device
Digital outputs
Digital output 1
Function 1 Common alarm EDS
Function 2 off
Function 3 off
Interfaces
DHCP off
IP address 192.168.0.5
Net mask 255.255.255.0
BCOM address system-1-0
Device address BS bus 1
Switching elements
Relay 1
Test on
Operating mode N/C operation
Function 1 Ins. alarm 1
Function 2 Connection fault
Function 3 off
Relay 2
Test on
Operating mode N/C operation
Function 1 Ins. alarm 2
Function 2 Device fault
Function 3 Connection fault
EDS
Mode auto
Current 10 mA
Parameter Value
