CommissioningCommissioning
iso685-D-P_D00170_00_M_XXDE/06.2016
34
7.2.6 Setting EDS current
Set the maximum locating current.
EDS441: 1-5 mA
EDS440: 10-50 mA
For further information, refer to “Current” on page 51.
7.2.7 Set response value R
an1
for alarm 1
You can set the prewarning response value here.
A value of 100 Ω/V is recommended for prewarning.
7.2.8 Set response value R
an2
for alarm 2
You can set the response value for the main alarm here.
A value of 50 Ω/V is recommended for the main alarm.
Current
6.6.9
o 1mA
o 1.8mA
o 2.5mA
o 5mA
• 10mA
lle
Commissioning 6.6
Please select
the locating
current
8/11
Alarm 1 5.6.8
40 kΩ
Min. 1 kΩ
Max.
10MΩ
lle
Commissioning 5.6
Please set a
response value
for R(an1) for
Alarm 1.
7/9
Alarm 2 5.6.9
10 kΩ
Min.
Max.
1 kΩ
10MΩ
lle
Commissioning 5.6
Please set a
response value
for R(an2) for
Alarm 2.
8/9
7.3 Recommissioning
If the device has already been put into operation once, the self test will be carried out
shortly after connecting the supply voltage. The commissioning wizard will not restart.
You can restart the commissioning wizard using the following menu path:
Menu/Device settings/Commissioning
This menu can be used to modify settings made previously.
Observe device status!
Once initial commissioning has been completed and the initial measure-
ment has been taken, the device changes from the alarm state to normal
state by adhering to the set response values.
