BENDIX TABS-6 User Manual

16
Diagnostic Trouble Codes (DTCs) (continued)
1st
Digit
2nd
Digit
Diagnostic Code
Description
Possible Causes / Repair Information
J1587
(SID/
FMI)
J1939
(SPN/
FMI)
Trailer System Braking
9 1
Valve Plausibility
Error-Extended
Brake Application
• Verify that there is no residual pressure in the trailer’s control
(service) line.
• After repairs — or if no issues are found — clear the diagnostic code.
• If the diagnostic code persists, contact your local Bendix
representative before replacing the TABS‑6 Adv MC module.
057/07 1047/07
9 2
ABS Plausibility
Error-Excessive
ABS Activity
•Checkforcorroded/damagedwiringorconnectorsbetweentheECU
and the WSS.
• Check the air gap between the sensor and tone ring, pushing‑in
sensor(s) if needed.
•Rotatethewheelandverifyamin.of0.25VACsensoroutput@~
0.5RPS.
• Verify the condition of the sensor head.
• Verify the condition and retention power of the clamping sleeve.
• Verify the proper mounting of the exciter ring and condition of the
teeth.
• Check the wheel bearings for correct adjustment.
• Verify the sensor wire routing and clamping.
• After repairs — or if no issues are found — clear the diagnostic code.
• If the diagnostic code persists, contact your local Bendix
representative before replacing the TABS‑6 Adv MC module.
057/07 1047/07
9 3
TRSP Plausibility
Error-Excessive
TRSP Activity
• Clear the diagnostic codes.
• If the diagnostic code persists, contact your local Bendix
representative before replacing the TABS‑6 Adv MC module.
057/07 1047/07

BENDIX TABS-6 Specifications

General

Type	Trailer ABS Module
Operating Temperature Range	-40°C to +85°C
Protection Rating	IP67
Category	Automobile Accessories
Voltage	12V/24V
Communication	J1587/J1939
Mounting	Frame Mount
Manufacturer	BENDIX
System Type	ABS
Number of Channels	4S/2M
