BENDIX TABS-6 User Manual

17
1st
Digit
2nd
Digit
Diagnostic Code
Description
Possible Causes / Repair Information
J1587
(SID/
FMI)
J1939
(SPN/
FMI)
TABS‑6 Adv MC module
10 1
TABS‑6 Adv MC
InternalError
• Check for damaged or corroded connectors.
• Check for damaged wiring.
• After repairs — or if no issues are found — clear the diagnostic code.
• If the diagnostic code persists, contact your local Bendix
representative before replacing the Bendix
®
TABS‑6
™
Adv MC
module.
254/12 629/12
10 2
TABS‑6 Adv MC
CongurationError
•VerifytheECUparametersandactualsysteminstallationare
compatible using the Bendix
®
ACom
®
diagnosticsoftware(version6.1
or higher).
•Re-programtheECUasnecessary.
• If necessary, contact your local Bendix representative to obtain the
correctcongurationdata.
254/13 629/13
10 3
TABS‑6 Adv MC
EEPROMError
•VerifytheECUparametersandactualsysteminstallationare
compatible using the Bendix
®
ACom
®
diagnosticsoftware(version6.1
or higher).
•Re-programtheECUasnecessary.
• If necessary, contact your local Bendix representative to obtain the
correctcongurationdata.
254/13 629/13
10 4
TABS-6AdvMCNot
Congured
•Re-programtheECUtobecompatibletotheactualsystem
congurationusingtheBendix
®
ACom
®
diagnostic software (version
6.1orhigher).
• If necessary, contact your local Bendix representative to obtain the
correctcongurationdata.
254/13 629/13
10 5
TABS‑6 Adv MC
EOLTestNot
Completed
• Perform the Installation Test using the Bendix
®
ACom
®
diagnostic
software(version6.1orhigher),orBendix
®
Trailer Information
Module.
254/14 629/14
Diagnostic Trouble Codes (DTCs) (continued)

BENDIX TABS-6 Specifications

General

Type	Trailer ABS Module
Operating Temperature Range	-40°C to +85°C
Protection Rating	IP67
Category	Automobile Accessories
Voltage	12V/24V
Communication	J1587/J1939
Mounting	Frame Mount
Manufacturer	BENDIX
System Type	ABS
Number of Channels	4S/2M
