TRK 502/ 502X
16
LOCATION OF PARTS
1. TACHOMETER
Tachometer indicates the revolution per minute of engine.
2. ADJUST BUTTON
Short press the button to switch between km/h and mph.Long press
the button to reset the "Trip" mileage.
3. SELECT BUTTON
Short press the button to switch between trip and odometer func-
tions on the meter.Press button “SELECT” for several seconds,
there will appear the interface for time adjustment: “SELECT” for
selection of digits of time display and “ADJUST” for adjustment of
each value.
4. WATER TEMPERATURE INDICATOR
This indicator indicates the temperature of cooling liquid. When the
pointer is in between C and H, the temperature is normal. It should
stop to check the water tank if the pointer is higher than H level.
5.ENGINE CONTROL SYSTEM TROUBLE INDICA-
TOR
Return to authorized dealer if this indicator is activated during
riding.
6.TURNING INDICATOR
The indication lamps would flash with the turning signals.
7. HIGH BEAM INDICATOR LAMP
When the high beam lamp of the headlamp turns on, the high
beam indicator lamp would be on.
8. NEUTRAL INDICATOR LAMP
When the transmission is in the neutral, the indicator lamp
would be on.
9.ENGINE OIL PRESSURE WARNING LAMP
When this indicator light up, that means the bike has the risk of
insufficient lubrication and should be checked/
repaired immediately.
10. CLOCK
It shows the time.
11. GEAR INDICATOR LAMP
Numbers on the meter indicate the gear positions of the
vehicle including 1, 2, 3, 4 ,5,and6.
12.ODOMETER & TRIP METER
Relative mileage (TRIP): it records the mileage the vehicle
covers in a period of time.Odometer (TOTAL): it records
the total mileage the vehicle has covered in km.
