TRK 502/ 502X
17
13. WATER TEMPERATURE INDICATOR
It should stop to check the water tank if the INDICATOR is light .
14.SPEEDOMETER
Speedometer shows the running speed, kilometers/hour.
15. FUEL LEVEL INDICATOR
It indicates the fuel level in the fuel tank.
16. ABS INDICATOR LIGHT (IF EQUIPPED)
1. ABS failure -- If any type of ABS failure is detected and stored, ABS
indicator light is lit and stays on after repaired, then ABS indicator
light will be unlit after the next Power switch ON/OFF and when
vehicle speed exceeds 5km/h.
2. ABS is under OFF mode --ABS indicator light Blink 1 time/1.27s
(Slow Blink)
3. When press the the ABS switch within 3s ~30s --ABS indicator
light Blink 1 time/0.32s(Quick Blink)
4. ABS is under ON mode -- When keyswitch turned on, the ABS
indicator lamp lit and stays activated, until the motorcycle drive o,
reaching about 3~5KM/H will the ABS indicator lamp be unlit.
LOCATION OF PARTS
Normally the ABS indicator light comes on when
the ignition switch is turned on and goes o
shortly after the vehicle starts moving. If the indi-
cator light shows any of the following, a fault or
faults may have occurred in the ABS. You should
have the vehicle checked by an authorized Benelli
dealer.
a. The light does not come on when the ignition
switch is turned on.
b. The light remains lit after the vehicle moving
over 5km/h.
Remember that the ABS does not function when
the indicator light is on, but if only the ABS system
fails (without any other malfunctions in mechanical
parts, for example, brake hoses, master cylinders,
brake calipers), the conventional brake system
should still work normally.
