24
5.
•
Fill: Crankcase
Oil quantity:
1.4L
6.
•
Check: Engine oil level
*************************************
ENGINE OIL PRESSURE INSPECTION
1.
•
Remove: Side Panels
2.
•
Inspect: Oil Pressure
*****************************************************
Inspection steps:
•
Slightly loosen the oil check bolt
1
.
Start the engine and keep it idling until the oil
begins to seep from the oil check bolt.
If no oil comes out after one minute, turn the
engine off so it will not seize.
Check oil passages and oil pump for damage
or leakage.
Start the engine after solving the problem(s),
and recheck the oil pressure.
Tighten the oil check bolt to specification.
CAUTION:
•
Start the engine and check the oil pres-
•
sure with the oil check bolt loosened.
Do not apply at high speeds more than
specified when checking the pressure.
NOTE:
Wipe any spilled oil off of the engine.
